XML Schema Documentation

Super-types:	None
Sub-types:	None

Name	PartialTerminationAmount
Used by (from the same schema document)	Model Group TerminationDetails.model
Abstract	no

XML Instance Representation

<...>
Start Choice [0..1]

<decreaseInNotionalAmount> Money </decreaseInNotionalAmount> [1]

'Specifies the fixed amount by which the Notional decreases due to the Partial Termination transaction.'

<outstandingNotionalAmount> Money </outstandingNotionalAmount> [1]

'Specifies the Notional amount after the Partial Termination.'

<decreaseInNumberOfOptions> xsd:decimal </decreaseInNumberOfOptions> [1]

'Specifies the fixed amount by which the Number of Options decreases due to the Partial Termination transaction.'

<outstandingNumberOfOptions> xsd:decimal </outstandingNumberOfOptions> [1]

'Specifies the Number of Options after the Partial Termination.'

End Choice
</...>

Schema Component Representation

<xsd:complexType name="PartialTerminationAmount">

<xsd:sequence>

<xsd:choice minOccurs="0">

<xsd:sequence>

<xsd:element name="decreaseInNotionalAmount" type=" Money "/>

<xsd:element name="outstandingNotionalAmount" type=" Money "/>

</xsd:sequence>

<xsd:sequence>

<xsd:element name="decreaseInNumberOfOptions" type=" xsd:decimal "/>

<xsd:element name="outstandingNumberOfOptions" type=" xsd:decimal "/>

</xsd:sequence>

</xsd:choice>

</xsd:sequence>

</xsd:complexType>
