XML Schema Documentation

Super-types:	None
Sub-types:	None

Name	CommodityBusinessCalendarTime
Abstract	no
Documentation	Specifies the time with respect to a commodity business calendar.

XML Instance Representation

<...>

<hourMinuteTime> HourMinuteTime </hourMinuteTime> [1]

'A time specified as Hour Ending in hh:mm:ss format where the second component must be \'00\', e.g. 11am would be represented as 11:00:00.'

<timeZone> TimeZone </timeZone> [1]

'An identifier for a specific location or region which translates into a combination of rules for calculating the UTC offset.'

<businessCalendar> CommodityBusinessCalendar </businessCalendar> [1]

'Identifies a commodity business day calendar.'

</...>

Schema Component Representation

<xsd:complexType name="CommodityBusinessCalendarTime">

<xsd:sequence>

<xsd:element name="hourMinuteTime" type=" HourMinuteTime "/>

<xsd:element name="timeZone" type=" TimeZone "/>

<xsd:element name="businessCalendar" type=" CommodityBusinessCalendar "/>

</xsd:sequence>

</xsd:complexType>
